With the '06, the code can be cleared using the Hand Shift Control Switch. The display showed 01, meaning one code stored (no picture). I was only interested in clearing the fault code, so I selected SH_ _62.
The "SH_ _?" selection can be scrolled up and down to any of the possibilities by using the TCS or RESET switches.
Yamaha motorcycle ecu diagnostic erase codes manual#
The '06 workshop manual indicates that error code 51 is "Shift actuator sensor signal is abnormal", which is consistant with its reluctance to change gear. SH_ _61 shows code 51, Shift Down Indicator Light is on Also the Shift Down Indicator Light was on - I take that to indicate the existence of at least one stored error code, as the Hand Shift Select Indicator Light did on the '06 to '12 FJR1300AS. Mine showed SH_ _61 (the stored errors selection), and 51, a stored error code. After about 2 seconds, the selected diagnostic screen appears. When the desired selection is highlighted (in my case MCU for the YCC-S system), press and hold both TCS and RESET switches. Using the TCS switch, the highlighted entry can be scrolled (possibly the RESET switch will scroll the other way). After about 8 seconds, the screen showed a menu with selections for ECU, MCU and SCU.ĭiagnostic selection. So, I turned off the ignition, held down the TCS and RESET switches, then turned on the ignition. After about 8 seconds, the screen showed "DIAG", but nothing I did would change it from that display. My first attempt, I turned on the ignition, then pressed and held the TCS and RESET switches. I set the Engine Stop Switch so that fuel pump wouldn't run. To enter diagnostic mode, firstly I released my Cruise Control Power Switch that I normally have held pressed - I don't know if this affects anything, but. (The Haynes manual that I have doesn't cover the YCC-S of the 2013/4, nor does it help with any diagnostic mode.) With no access to a Yamaha workshop manual for a 2014 FJR1300AS, but access to that of a 2006, I had to do a little experimenting. This shows how I navigated to the appropriate diagnostics. I had a peculiar episode when the bike refused to change into gear just after starting, then later behaved normally. However, it might be interesting if not actually useful to someone. The specifics will be of little value to the majority since it concerns my GenIII YCC-S, unavailable to the majority of Forum members. Demand ColorRite.This topic is only to show some of the mechanisms needed to use the diagnostics of the GenIII FJR. Get the job done right the first time by choosing only the very best touch up paint for your Yamaha motorcycle, ATV, UTV, boat, WaveRunner or outboard engine. Yamaha motorcycle paint, ATV and UTV paint, WaveRunner paint, snowmobile paint and outboard engine paint is also available. Otherwise, for your convenience we recommend using our paint selector to ensure accuracy. If you know your specific color name, paint options are listed below. Recommended by dealers and enthusiasts alike since 1988, ColorRite paint products are the highest quality available anywhere to ensure a spot-on match and durable finish.
